Two types of silicone sponge sheets with flame retardant UL94V-0.
* Up to 20 mm is available. Please contact us if there are any requests.
[Features]
- SSG type has heat resistance of 200°C, and the UL certified SSB type has heat resistance of 150°C.
Overview
Two types of silicone sponge sheets with flame retardant UL94V-0.
Features
- The SSG type is a UL-compliant product with heat resistance of 200°C. (Not a certified product.)
- The SSB type is a UL certified product with heat resistance of 150°C.
| Flame retardant Type | SSG Type | SSB Type | |
|---|---|---|---|
| Normal state physical property | Apparent density (g / cm3) | 0.50 | 0.30 |
| Tensile strength (MPa) | 1.2 | 0.4 | |
| Elongation (%) | 375 | 150 | |
| Tear strength (N / mm) | 3.9 | 1.1 | |
| Thermostability | Tensile strength change rate (%) | -42 | -12 |
| Elongation change rate (%) | -50 | 33 | |
| Solidity change (point) | 15 | 1 | |
| (Heat resistance test conditions) | 180℃×72H | 120℃×72H | |
| Ozone resistant properties | No indication | No indication | |
| Thermostability test (UL94) | V-0 conform | V-0 certified | |
(Numerical values in the tables are examples of characteristics not standard values.)
